Features:
1. PLC-based control system, automatic protection functions;
2. Touch screen controls, English language;
3. The unit of forced loading of raw materials, increased the ability to load powder, solved the problem of stratification of large and small granules;
4. Central automatic lubrication system;
5. Forming in two cycles - the main and pre-pressing;
6. Conforms to GMP;
7. Easy to disassemble and clean.
| Technical Parameters | |||
| Model | GZPK-83 | GZPK-65 | GZPK-51 |
| Punch pin number | 83 | 65 | 51 |
| Rotating speed of punch disk / R.P.M | 5-80 | ||
| Minimum production (tablets/h)Maximum production (tablets/h) | 49800~796800 | 39000~624000 | 30600~489600 |
| Main motor powder (KW) | 11 | ||
| Maximum pressure KN(10KN=0.98T) | 100 | 100 | 100 |
| Maximum pre-pressure (KN) | 100 | 100 | 100 |
| Maximum tablet diameter mm | 13 | 16 | 25 |
| Maximum filling depth | 16 | 16 | 20 |
| Maximum tablet thickness mm | 8.5 | 8.5 | 8.5 |
| Pitch diameter mm | 720 | 720 | 720 |
| Punch pin handle diameter mm | 19 | 19 | 25.35 |
| Middle die height | 22.22 | 22.22 | 23.8 |
| Weight (Kg) | 5500 | ||
